Image for illustration purposes. Refer to the product specifications.

SEL 1616 H11

Sign in to view prices.

SEL 1616 H11 (product code: AL-814777) is an Alamach cutting tool solution in the External Threading Tools – Metric (ISO) range. Review dimensions, geometry, clamping and insert compatibility in the technical specifications table.

Cutting inserts shown in the images are not included in the product package. Sold separately.

Product Code:AL-814777

External / Internal Turning

E (External Turning)

LF – Tool Length

H (100 mm)

Shim System

- (Without Shim)

Insert Brand

ISO

Clamping Screw

AL-SP029

ICS – Insert Clamping System

S (Screw Clamping System)

HAND – Cutting Direction

L (Left-hand)

B – Shank Width

16

H – Shank Height

16

Insert Code

11 EL

L – Insert Cutting Edge Length

11 (11)

Wrenches

AL-SP032

Product Barcode 8684514814777
